ES500PV Solar Water Pump Inverter

Product Features：

This series of solar water pump drivers is a special inverter for photovoltaic power generation to drive AC water pumps. It inverts the DC power emitted by the solar module group into AC power to drive various AC water pumps. The driver adopts high-precision and fast MPPT algorithm to track the output of the solar module through the maximum power point to maximize the drive of the water pump motor. At the same time, it also supports AC input. When the power of the solar module is insufficient, it can accept the AC input from the grid to achieve all-day work and various needs.

Technical Features：

1. Superior performance, built-in high-precision and fast MPPT algorithm, tracking the maximum power of the solar module, and the efficiency can reach 99%;

2. The model fully supports single-phase 220V, three-phase 220V and three-phase 380V water pumps, with power ranging from 0.4kW to 400kW;

3. Safe and reliable - with over-voltage protection, over-current protection, over-temperature automatic frequency reduction and other protection functions;

4. Easy to operate - easy to install, no need to set parameters, it can be used immediately, and it has the function of one-key recovery of parameters;

5. In addition to a wide range of DC power input, it can also accept AC power input;

6. Application occasions - In areas with abundant sunshine and shortage of mains power, it is widely used in farm irrigation, animal husbandry, production and living water supply.
