ES600 Electro-hydraulic Servo Drive

Technical features

a) CANBUS and analog communication mode can be selected, fast response time and simple operation.

b) Using CANBUS communication, easy to realize parallel connection of multiple pumps in single machine, combined flow and shunt control

c) Drive with motor temperature protection function

d) Oil pressure sensor power short circuit protection function

e) Easy to realize double-displacement piston pump pressure control

Advantages

a) Energy saving: precise speed control to achieve maximum energy saving.

b) High precision: more accurate speed control, high product repeatability

c) Professional: designed for injection molding machine oil pump control, easy and simple debugging and installation.

d) High reliability: large design margin, using the metal structure of the resolver as the speed feedback element, adapt to the injection molding machine

It can be used in high temperature, oil and vibration environment of injection molding machine.

e) Low noise: servo drive designed for injection molding machine, fully using the high performance of servo motor, the whole machine operation

The noise is significantly reduced.
